Insulating anchor TOGE TIDS | TIDR

Insulation panel fasteners

TOGE TID

The insulating anchor for cold-, heat- and fire-protection

Whether for use in dry interiors or in a damp environment, the TOGE TID insulating anchor is exactly the right choice for the economical fastening of your insulation material: For an application in dry environments, choose the standard version made of galvanized steel.

For use in a damp environment, choose the A2 stainless steel version.

An additional disc with Ø 80mm is additionally available for fastening insulation material with a very soft surface structure. With the additionally available plastic caps with sauerkraut structure in different colors, you create a coherent look over the entire surface.

TOGE TID – At a Glance



Cover cap

Cover caps with textured structure made of polyethylene in three different colors for a coherent look of the entire surface.


Corrosion resistance

The A2 stainless steel design provides optimum corrosion protection even in humid environments.

Fire protection

Fire protection up to fire resistance class R120.

Maximum thickness

Screw lengths up to 300 mm enable the fastening of insulating panels up to a thickness of 260 mm.

Headshapes and Materials


01 | TIDS

Insulating anchor – Steel, zinc plated

01 | TIDS

Insulating anchor – Steel, zinc plated


02 | TIDR

Insulating anchor – Steel, stainless A2

02 | TIDR

Insulating anchor – Steel, stainless A2


03 | TID-E

Cover caps in different colors – polyethylene

03 | TID-E

Cover caps in different colors – polyethylene


04 | TIDS T

Additional disc Ø 80mm – Steel, zinc plated

04 | TIDS T

Additional disc Ø 80mm – Steel, zinc plated


05 | TIDR T

Additonal disc Ø 80mm – Steel, stainless A2

05 | TIDR T

Additonal disc Ø 80mm – Steel, stainless A2


06 | TIDR T without embossing

Additional disc Ø 80mm – Steel, zinc plated

06 | TIDR T without embossing

Additional disc Ø 80mm – Steel, zinc plated


07 | TIDS-K

Insulating anchor with pre-mounted large cap, white – steel, zinc plated

07 | TIDS-K

Insulating anchor with pre-mounted large cap, white – steel, zinc plated


08 | TIDR-K

Insulating anchor with pre-mounted large cap, white – Steel, stainless A2

08 | TIDR-K

Insulating anchor with pre-mounted large cap, white – Steel, stainless A2



Which product is right for you?

Do you need support?
We will be happy to help!

Call us: +49 911 659 68-54


Application Examples




Underground garage and basement walls




Underground parking and basement ceilings


Approval | Installation Instructions | Technical Information


Approval


Base Materials

Approval for concrete strength classes from C20/25 to C50/60.
Cracked and non-cracked concrete.

This is how simple the installation works

  1. Create borehole.
  2. Clean the borehole thoroughly.
  3. Drive the insulating anchor through the insulating plate with a hammer.
  4. The dowel plate must rest completely on the attachment part.

Downloads




Product
Information



Technical
Data



General technical
approval Z-21.8-1970



Certificate of conformity
Z-21.8-1970
